4-95
4-2 Function Mode
4
Functions
1020h FV start frequency A011 R/W 0 to 4000 0.1 [Hz]
1022h FV end frequency A012 R/W 0 to 4000 0.1 [Hz]
1023h FV start ratio A013 R/W 0 to 100 1 [%]
1024h FV end ratio A014 R/W 0 to 100 1 [%]
1025h FV start selection A015 R/W
00: Start frequency A011
01: 0 Hz
⎯
1026h FV, FI sampling A016 R/W 1 to 17 ⎯
1029h Multi-step speed reference 0 A020 R/W 0.0/Starting frequency to 4000 0.1 [Hz]
150Fh
2nd multi-step speed
reference 0
A220 R/W 0.0/Starting frequency to 4000 0.1 [Hz]
102Bh Multi-step speed reference 1 A021 R/W
0.0/Starting frequency to 4000 0.1 [Hz]
102Dh Multi-step speed reference 2 A022 R/W
102Fh Multi-step speed reference 3 A023 R/W
1031h Multi-step speed reference 4 A024 R/W
1033h Multi-step speed reference 5 A025 R/W
1035h Multi-step speed reference 6 A026 R/W
1037h Multi-step speed reference 7 A027 R/W
1039h Multi-step speed reference 8 A028 R/W
103Bh Multi-step speed reference 9 A029 R/W
103Dh
Multi-step speed
reference 10
A030 R/W
103Fh
Multi-step speed
reference 11
A031 R/W
1041h
Multi-step speed
reference 12
A032 R/W
1043h
Multi-step speed
reference 13
A033 R/W
1045h
Multi-step speed
reference 14
A034 R/W
1047h
Multi-step speed
reference 15
A035 R/W
1048h Jogging frequency A038 R/W 0 to 999 0.01 [Hz]
1049h Jogging stop selection A039 R/W
00: Free-run stop
01: Deceleration stop
02: DC injection braking stop
⎯
104Ah Torque boost selection A041 R/W
00: Manual torque boost only
01: Simple torque boost
⎯
1510h 2nd torque boost selection A241 R/W
104Bh Manual torque boost voltage A042 R/W
0 to 200 0.1 [%]
1511h
2nd manual torque boost
voltage
A242 R/W
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
