4-96
4-2 Function Mode
4
Functions
104Ch
Manual torque boost
frequency
A043 R/W
0 to 500 0.1 [%]
1512h
2nd manual torque boost
frequency
A243 R/W
104Dh V/f characteristics selection A044 R/W
00: VC
01: 1.7th power of VP
06: Special VP
⎯
1513h
2nd V/f characteristics
selection
A244 R/W
104Eh Output voltage gain A045 R/W
20 to 100 1. [%]
1514h 2nd output voltage gain A245 R/W
1051h
DC injection braking
selection
A051 R/W
00: Disabled
01: Enabled during stop
02: Output frequency<A052 DB
⎯
1052h
DC injection braking
frequency
A052 R/W 0 to 600 0.1 [Hz]
1053h
DC injection braking delay
time
A053 R/W 0 to 50 0.1 [s]
1054h DC injection braking power A054 R/W 0 to 100 1. [%]
1055h DC injection braking time A055 R/W 0 to 600 0.1 [s]
1056h
DC injection braking method
selection
A056 R/W
00: Edge operation
01: Level operation
⎯
105Ah Frequency upper limit A061 R/W
0.0/Frequency lower limit
: A062 x 10 to Maximum frequency
: A004 x 10
0.1 [Hz]
1517h 2nd frequency upper limit A261 R/W
0.0/2nd frequency lower limit
: A262 x 10 to 2nd max. frequency
: A204 x 10
0.1 [Hz]
105Bh Frequency lower limit A062 R/W
0.0/Starting frequency
: b082 × 10 to Frequency upper limit
: A061 × 10
0.1 [Hz]
1518h 2nd frequency lower limit A262 R/W
0.0/Starting frequency
: b082 x 10 to 2nd frequency upper limit
: A261x10
0.1 [Hz]
105Dh
1060h
1063h
Jump frequency 1
Jump frequency 2
Jump frequency 3
A063,
A065,
A067
R/W 0 to 4000 0.1 [Hz]
105Eh
1061h
1064h
Jump frequency width 1
Jump frequency width 2
Jump frequency width 3
A064,
A066,
A068
R/W 0 to 100 0.1 [Hz]
1068h PID selection A071 R/W
00: Disabled
01: Enabled
⎯
1069h PID P gain A072 R/W 2 to 50 0.1
106Ah PID I gain A073 R/W 0 to 1500 0.1 [s]
106Bh PID D gain A074 R/W 0 to 1000 0.1 [s]
106Ch PID scale A075 R/W 1 to 9999 0.01
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
