4-2 Function Mode
4
Functions
106Dh PID feedback selection A076 R/W
00: Feedback (FI)
01: Feedback (FV)
02: External communication
10: Operation function output
-⎯
106Eh Reverse PID function A077 R/W
00:
OFF (Deviation = Target value -
Feedback value)
01:
ON (Deviation = Feedback value -
Target value)
⎯
106Fh PID output limit function A078 R/W 0 to 1000 0.1 [%]
1070h AVR selection A081 R/W
00: Always ON
01: Always OFF
02: OFF during deceleration
⎯
1071h AVR voltage selection A082 R/W
200-V class
0: 200
1: 215
2: 220
3: 230
4: 240
400-V class
0: 380
1: 400
2: 415
3: 440
4: 460
5: 480
⎯
1072h RUN mode selection A085 R/W
00: Normal operation
01: Energy-saving operation
⎯
1073h
Energy-saving response/
accuracy adjustment
A086 R/W 0 to 1000 0.1 [%]
1074h
Acceleration time 2
A092
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
1075h
A092
(LSB)
R/W
1519h
2nd acceleration time 2
A292
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
151Ah
A292
(LSB)
R/W
1076h
Deceleration time 2
A093
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
1077h
A093
(LSB)
R/W
151Bh
2nd deceleration time 2
A293
(MSB)
R/W
1 to 300000
The second decimal place is ignored
when the value is over 10000 (100.0
seconds).
0.01 [s]
151Ch
A293
(LSB)
R/W
Register
No.
Function name
Parameter
No.
R/W
Function
Monitor or data range
Resolution
