323
PLC Setup Section 7-1
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Pulse Output 0 Search Compensation Value (Origin Compensation)
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Pulse Output 0 Origin Search Acceleration Rate
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Pulse Output 0 Origin Search Deceleration Rate
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Pulse Output 0 Limit Input Signal Type
Programming
Console
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
+264 00 to 15 80000000 to
7FFFFFFF hex
(See note.)
---
Sets the pulse output 0 origin com-
pensation (−2,147,483,648 to
2,147,483,647).
--- When operation
starts
+265 00 to 15
Programming
Console
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
+266 00 to 15 Pre-Ver. 2.0 CPU
Units: 0001 to
07D0 hex
CPU Units Ver.
2.0: 0001 to FFFF
hex
(See note.)
--- Sets the origin search acceleration
rate for pulse output 0.
Pre-Ver. 2.0 CPU Units:
1 to 2,000 pulses/4 ms
CPU Units Ver. 2.0:
1 to 65,535 pulses/4 ms
--- When operation
starts
Programming
Console
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
+267 00 to 15 Pre-Ver. 2.0 CPU
Units: 0001 to
07D0 hex
CPU Units Ver.
2.0: 0001 to FFFF
hex
(See note.)
--- Sets the origin search deceleration
rate for pulse output 0.
Pre-Ver. 2.0 CPU Units:
1 to 2,000 pulses/4 ms
CPU Units Ver. 2.0:
1 to 65,535 pulses/4 ms
--- When operation
starts
Programming
Console
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
+268 00 to 03 0 hex: NC
1 hex: NO
0 hex Specifies whether the limit input sig-
nal for pulse output 0 is normally
closed or normally open.
--- When operation
starts
