Host Link Commands Section 6-3
Response Format An end code of 00 indicates normal completion.
Parameters Name, TC Number (Command)
In “Name,” specify the name of the instruction, in four characters, for changing
the SV. In “TC number,” specify the timer/counter number used for the instruc-
tion.
Operand, New SV (Response)
In “Operand,” specify the name that indicates the SV classification. Specify
the name in four characters. In “SV,” specify either the word address where
the SV is stored or the constant SV.
6-3-21 STATUS READ –– MS
Reads the PC operating conditions.
Command Format
Response Format An end code of 00 indicates normal completion.
@ W% x 16
0
x 10
0
x 10
1
x 16
1
↵
Node no. Header
code
TerminatorFCSEnd code
Instruction name Classification TC number
range
OP1 OP2 OP3 OP4
T I M (Space) TIMER 0000 to 0511
T I M H HIGH-SPEED TIMER
C N T (Space) COUNTER
C N T R REVERSIBLE COUNTER
Operand Classification Constant or
word address
OP1 OP2 OP3 OP4
C I O (Space) IR or SR 0000 to 0252
L R (Space) (Space) LR 0000 to 0063
H R (Space) (Space) HR 0000 to 0099
A R (Space) (Space) AR 0000 to 0027
D M (Space) (Space) DM 0000 to 6655
DM* (Space) DM (indirect) 0000 to 6655
C O N (Space) Constant 0000 to 9999
@ MSx 10
0
x 10
1
↵
Node no. Header
code
TerminatorFCS
@ MS x 16
2
x 10
0
x 10
1
x 16
1
x 16
0
x 16
3
x 16
0
x 16
1
↵
Node no. Header
code
Status dataEnd code TerminatorFCS
Message
16 characters
