Omron CPM1 Programming Manual

386
Host Link Commands Section 6-3
6-3-28 PC MODEL READ –– MM
Reads the model type of the PC.
Command Format
Response Format An end code of 00 indicates normal completion.
Parameters Model Code
“Model code” indicates the PC model in two digits hexadecimal.
6-3-29 TEST–– TS
Returns, unaltered, one block of data transmitted from the host computer.
Command Format
Response Format An end code of 00 indicates normal completion.
Parameters Characters (Command, Response)
For the command, this setting specifies any characters other than the carriage
return (CHR$(13)). For the response, the same characters as specified by the
command will be returned unaltered if the test is successful.
@ MMx 10
0
x 10
1
↵
Node no. Header
code
TerminatorFCS
@ MMx 10
0
x 10
1
x 16
1
x 16
0
↵
*
x 16
1
x 16
0
Node no. Header
code
TerminatorFCSEnd code Model
code
Model code Model
01 C250
02 C500
03 C120
0E C2000
10 C1000H
11 C2000H/CQM1/CPM1/CPM1A/SRM1
12 C20H/C28H/C40H/C200H/C200HS
20 CV500
21 CV1000
22 CV2000
40 CVM1-CPU01-E
41 CVM1-CPU11-E
42 CVM1-CPU21-E
@ TSx 10
0
x 10
1
↵
Node no. Header
code
Characters
122 characters max.
TerminatorFCS
@ TSx 10
0
x 10
1
↵
Node no. Header
code
Characters
122 characters max.
TerminatorFCS
