Omron CPM1 Programming Manual

385
Host Link Commands Section 6-3
Forced set/Reset/Cancel data (Command)
If a timer or counter completion flag is specified, only bit 15 is effective and all
other bits will be ignored. Only force-setting and force-resetting are possible
for timers/counters.
If a word address is specified, the content of the word specifies the desired
process for each bit in the specified word, as shown in the following table.
The bits that are merely set or reset may change status the next time the pro-
gram is executed, but bits that are force-set or force-reset will maintain the
forced status until it is cleared.
Response Format An end code of 00 indicates normal completion.
6-3-27 FORCED SET/RESET CANCEL –– KC
Cancels all forced set and forced reset bits (including those set by FORCED
SET, FORCED RESET, and MULTIPLE FORCED SET/RESET). If multiple
bits are set, the forced status will be cancelled for all of them. It is not possible
to cancel bits one by one using KC.
Command Format
Response Format An end code of 00 indicates normal completion.
Name Classification Word address setting range
OP1 OP2 OP3 OP4 CQM1 PCs CPM1/CPM1A/SRM1
PCs
CI
O
(Space) IR or SR 0000 to 0252 0000 to 0019
0200 to 0252
L R (Space) (Space) LR 0000 to 0063 0000 to 0015
H R (Space) (Space) HR 0000 to 0099 0000 to 0019
A R (Space) (Space) AR 0000 to 0027 0000 to 0015
T I M (Space) Completion Flag (timer) 0000 to 0511 0000 to 0127
T I M H Completion Flag (high-speed timer)
C N T (Space) Completion Flag (counter)
C N T R Completion Flag (reversible counter)
Hexadecimal setting Process
0000 No action (bit status not changed)
0002 Reset
0003 Set
0004 Forced-reset
0005 Forced-set
0008 Forced set/reset status cancel
@ FKx 10
0
x 10
1
x 16
1
x 16
0
↵
Node no. Header
code
TerminatorFCSEnd code
@ KCx 10
0
x 10
1
↵
Node no. Header
code
TerminatorFCS
@ KCx 10
0
x 10
1
x 16
1
x 16
0
↵
Node no. Header
code
TerminatorFCSEnd code
