421
CPM1/CPM1A Cycle Time and I/O Response Time Section 7-2
78 SDEC 51.1 When decoding word to word 5.6
96.3 When decoding *DM to *DM
80 DIST 39.1 When setting a constant to a word + a word 5.6
40.9 When setting a word to a word + a word
84.7 When setting *DM to *DM +*DM
63.4 When setting a constant to a stack
65.0 When setting a word to a stack
109.6 When setting *DM to a stack via *DM
81 COLL 42.6 When setting a constant + a word to a word 5.6
43.6 When setting a word + a word to a word
83.4 When setting *DM + *DM to *DM
78.0 When setting a word + constant to FIFO stack
79.2 When setting a word + word to FIFO stack
1.76 ms When setting a *DM + *DM to
FIFO stack via *DM
66.8 When setting a word + constant to LIFO stack
68.0 When setting a word + word to LIFO stack
112.0 When setting a *DM + *DM to
LIFO stack via *DM
82 MOVB 32.5 When moving constant to word 5.6
37.5 When moving word to word
79.1 When moving *DM to *DM
83 MOVD 28.3 When moving constant to word 5.6
33.3 When moving word to word
75.5 When moving *DM to *DM
84 SFTR 39.3 Shifting 1 word 5.6
52.9 Shifting 10 word
1.42 ms Shifting 1,024 words using *DM
85 TCMP 57.7 Comparing constant to word-set table 5.6
58.9 Comparing word to word-set table
101.9 Comparing *DM to *DM-set table
86 ASC 56.7 Word word 5.6
103.9 *DM *DM
89 INT 32.3 Set masks via word 5.6
46.3 Set masks via *DM
29.1 Clear interrupts via word
43.1 Clear interrupts via *DM
27.3 Read mask status via word
41.5 Read mask status via *DM
29.7 Change counter SV via word
43.7 Change counter SV via *DM
15.3 Mask all interrupts via word
15.3 Mask all interrupts via *DM
15.9 Clear all interrupts via word
15.9 Clear all interrupts via *DM
91 SBS 36.6 Any 5.5
92 SBN 1.7 1.7
93 RET 15.0 2.5
Code Mnemonic ON execution
time (µs)
Conditions (Top: min.; bottom: max.) OFF execution time (µs)
