Omron CPM1 Programming Manual

431
SRM1 Cycle Time and I/O Response Time Section 7-3
68 BCMP* 41.4 Comparing constant, results to word 3.0
41.9 Comparing word, results to word
64.5 Comparing *DM, results to *DM
69 STIM* 34.7 Word specification, one-shot timer start 3.0
49.5 *DM specification, one-shot timer start
35.3 Word specification, scheduled interrupt start
50.0 *DM specification, scheduled interrupt start
33.9 Words specification, timer read
49.5 *DM specification timer read
11.4 Word specification, timer stop
70 XFER 22.9 When transferring a constant to a word 3.0
24.0 When transferring a word to a word
902.0 When transferring 1,024 words using *DM
71 BSET 15.2 When setting a constant to 1 word 3.0
15.7 When setting word constant to 10 words
565.2 When setting *DM to 1,024 words
73 XCHG 16.2 Word → word 3.1
31.5 *DM → *DM
74 SLD 13.6 Shifting 1 word 3.0
26.7 Shifting 10 word
1.54 ms Shifting 1024 words using *DM
75 SRD 13.6 Shifting 1 word 3.0
26.6 Shifting 10 word
1.54 ms Shifting 1,024 words using *DM
76 MLPX 25.5 When decoding word to word 3.0
48.9 When decoding *DM to *DM
77 DMPX 35.1 When encoding word to word 3.0
58.1 When encoding *DM to *DM
78 SDEC 26.8 When decoding word to word 2.9
49.9 When decoding *DM to *DM
80 DIST 21.3 When setting a constant to a word + a word 3.0
21.9 When setting a word to a word + a word
45.7 When setting *DM to *DM +*DM
34.3 When setting a constant to a stack
35.3 When setting a word to a stack
59.3 When setting *DM to a stack via *DM
81 COLL 21.4 When setting a constant + a word to a word 3.0
21.8 When setting a word + a word to a word
44.9 When setting *DM + *DM to *DM
34.0 When setting a word + constant to FIFO stack
33.9 When setting a word + word to FIFO stack
892.0 When setting a *DM + *DM to
FIFO stack via *DM
35.4 When setting a word + constant to LIFO stack
36.1 When setting a word + word to LIFO stack
60.5 When setting a *DM + *DM to
LIFO stack via *DM
Code Mnemonic ON execution
time (µs)
Conditions (Top: min.; bottom: max.) OFF execution time (µs)

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
