5-57
5-16 User Parameters
5
Operating Functions
Explanation of Settings
• Use this parameter to assign the function of General-purpose Output 1 (OUTM1: CN1 pin 12).
Explanation of Settings
• Use this parameter to set the operating method for the 17-bit absolute encoder.
• The setting of this parameter is disabled if a 5-core 2,500-pulse/revolution incremental encoder is
used.
Pn0A
General-purpose Output 1 Selection
Setting range 0 to 8 Unit --- Default setting 1
Power OFF→ON
---
Setting Explanation
0 Output during torque limit
1 Zero speed detection output
2 Warning output for over regeneration, overload, absolute encoder battery, or fan lock
3 Over regeneration warning output
4 Overload warning output
5 Absolute encoder battery warning output
6 Fan lock warning output
7 Reserved
8 Speed conformity output
Pn0B
Operation Switch When Using Absolute Encoder
Setting range 0 to 2 Unit --- Default setting 0
Power OFF→ON
Yes
Setting Explanation
0 Use as absolute encoder.
1 Use as incremental encoder.
2 Use as absolute encoder but ignore multi-turn counter overflow.
To Next Page
