5-58
5-16 User Parameters
5
Operating Functions
Explanation of Settings
• Use this parameter to select the baud rate for RS-232 communications.
• Baud rate error: ±0.5%.
Explanation of Settings
• Use this parameter to select the baud rate for RS-485 communications.
• Baud rate error: ±0.5%.
Explanation of Settings
• Front panel key operations can be limited to Monitor Mode. This function can be used to prevent
unintended changes to parameters because of incorrect key operations.
• Even if this parameter is set to 1, parameters can be changed by using communications.
• Use communications to return this parameter to 0.
Pn0C
RS-232 Baud Rate Setting
Setting range 0 to 5 Unit --- Default setting 2
Power OFF→ON
Yes
Setting Explanation
0 2,400 bps
1 4,800 bps
2 9,600 bps
3 19,200 bps
4 38,400 bps
5 57,600 bps
Pn0D
RS-485 Baud Rate Setting
Setting range 0 to 5 Unit --- Default setting 2
Power OFF→ON
Yes
Setting Explanation
0 2,400 bps
1 4,800 bps
2 9,600 bps
3 19,200 bps
4 38,400 bps
5 57,600 bps
Pn0E
Front Key Protection Setting
Setting range 0 to 1 Unit --- Default setting 0
Power OFF→ON
Yes
Setting Explanation
0 All enabled
1 Limited to Monitor Mode
To Next Page
