Omron R88D-GT series User Manual

2-51
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
Note 1. The standard models have a straight shaft.
Note 2. Models with a key and tap are indicated with “J” at the end of the model number (the suffix shown in the
box). (Example: R88G-HPG32A051K0BJ)
Note 3. The diameter of the motor shaft insertion hole is the same as the shaft diameter of the corresponding
motors.
Model
Dimensions (mm)
LM LR C1 C2 D1 D2 D3 D4 D5 E F1 F2
1 kW
1/5 R88G-HPG32A051K0B
@ 104 133 120
122 dia.
135 100 115 114 84 98 12.5 35
1/11 R88G-HPG32A111K0B@ 104 133 120
122 dia.
135 100 115 114 84 98 12.5 35
1/21 R88G-HPG32A211K0B
@ 104 133 120
122 dia.
135 100 115 114 84 98 12.5 35
1/33 R88G-HPG32A331K0B@ 104 133 120
122 dia.
135 100 115 114 84 98 12.5 35
1/45 R88G-HPG50A451K0B
@ 123 156 170
170 dia.
190 100 165 163 122 103 12.0 53
1.5 kW
1/5 R88G-HPG32A052K0B@ 110 133 120
135 dia.
135 115 115 114 84 98 12.5 35
1/11 R88G-HPG32A112K0B
@ 110 133 120
135 dia.
135 115 115 114 84 98 12.5 35
1/21 R88G-HPG32A211K5B@ 110 133 120
135 dia.
135 115 115 114 84 98 12.5 35
1/33 R88G-HPG50A332K0B
@ 123 156 170
170 dia.
190 115 165 163 122 103 12.0 53
1/45 R88G-HPG50A451K5B@ 123 156 170
170 dia.
190 115 165 163 122 103 12.0 53
2 kW
1/5 R88G-HPG32A052K0B
@ 110 133 120
135 dia.
135 115 115 114 84 98 12.5 35
1/11 R88G-HPG32A112K0B@ 110 133 120
135 dia.
135 115 115 114 84 98 12.5 35
1/21 R88G-HPG50A212K0B
@ 123 156 170
170 dia.
190 115 165 163 122 103 12.0 53
1/33 R88G-HPG50A332K0B@ 123 156 170
170 dia.
190 115 165 163 122 103 12.0 53
3 kW
1/5 R88G-HPG32A053K0B
@ 107 133 120 130×130 135 145 115 114 84 98 12.5 35
1/11 R88G-HPG50A113K0B@ 123 156 170
170 dia.
190 145 165 163 122 103 12.0 53
1/21 R88G-HPG50A213K0B
@ 123 156 170
170 dia.
190 145 165 163 122 103 12.0 53
4 kW
1/5 R88G-HPG32A054K0B@ 129 133 120 130×130 135 145 115 114 84 98 12.5 35
1/11 R88G-HPG50A115K0B
@ 149 156 170 130×130 190 145 165 163 122 103 12.0 53
5 kW
1/5 R88G-HPG50A055K0B@ 149 156 170 130×130 190 145 165 163 122 103 12.0 53
1/11 R88G-HPG50A115K0B
@ 149 156 170 130×130 190 145 165 163 122 103 12.0 53
