14
A Handle
Use this to raise and lower the cover. The laser is automatically disabled
when the cover is opened.
B Cover
The cover provides access to the main bay for placing and retrieving
materials, as well as fixing the laser path alignment and other
maintenance.
C Viewing Window
This polycarbonate window protects you and others from the laser and
its reflection, allowing monitoring of the engraving process. However,
you should never stare continuously at the laser during operation, even
through the window.
D X-Axis Rail
The X-axis rail supports the movement of the laser head left and right
across the workbed. It also holds the 2nd mirror and the LED light that
illuminates the workbed.
E Laser Head
The laser head holds the 3rd mirror, the focus lens, the air assist outlet,
and the nozzle. There are two separate nozzles: one for engraving metal
and the other for other materials. The laser head is also motorized and
controlled as the engraver’s Z axis.
F
Rotary Axis
Switch & Port
Four-pin rotary axes can be connected to this port to engrave curved
surfaces. The rotary axis replaces the Y axis during use.
G Control Panel
This panel offers parameter adjustment and immediate control of the
engraving process, including manual movement of the laser head and
firing of the laser. It is also the location of the engraver’s emergency
stop, motorized workbed controls, and ammeter.
H Y-Axis Rails
These rails support the movement of the X-axis rail up and down the
workbed.
I Workbed
The workbed can be adjusted in height to fit thinner and thicker
materials, as well as adjusted between the aluminum knife blade and
steel saw blade platforms. The open design allows better airflow
beneath the material for stronger, faster, and cleaner engraving.
J
Front Pass-
Through Door
This door opens to allow larger pieces of material to be fed through the
workbed. When open, care must be taken to avoid exposure to the laser
beam or its reflection.
K Status Light
This LED light strip displays the engraver’s current status: blue in
standby, green during active lasing, and red for errors.
