Omtech PRO 3655 - Technical Specifications

11
2. Introduction
2.2 Technical Specifications
Model PRO 3655
Laser Tube
Diameter 3.15 in. 80 mm
Length 57.1 i n. 1450 mm
Max. Input Power (Laser and Motors) 1300 W
Rated Power 130 W 150 W
Wavelength 10640 nm
Focus Lens
Diameter 0.79 in. 20 mm
Thickness 0.08 in. 2 mm
Focal Length 2.5 in. 63.5 mm
Material Znse
Molybdenum Mirror
Diameter 0.98 in. 25 mm
Thickness 0.12 in. 3 mm
Rated Voltage/Frequency AC 110 V–120 V 60 Hz
Expected Service Life
at <40% / 40–70% / >70% Power
11000 / 9000 / 7000 hr
Processing Area 55.1×35.4 in 1400×900 mm
Front/Back Pass-Through Size 40.5×1.5 in. 1030×40 mm
Left/Right Side Pass-Through Size 25.5×1.5 in. 650×40 mm
Max. Height Adjustment 6.30 in. 160 mm
Max. Material Height 5.91 in. 150 mm
