3.7 Air Assist System Installation
The air assist system for normal non-metal cutting and engraving should arrive preinstalled and
correctly wired.
1. Simply check that it is correctly configured
and connected as shown.
If any tubing or wiring needs to be reconnected,
shut off all power to the machine (including by
pressing the emergency stop) before adjusting
anything.
2. Check that its air intake filter is in place,
clean, and not obstructed by any nearby
objects.
