Panasonic Lumix S1H

1. Introduction
29
4
3
2
1
6
7
15
16
5
8
9
12
13
14
10
11
1 Dioptre adjustment dial (l 68)
2
Operation lock lever (l 67)
3
[(] (Playback) button (l 347)
4
Monitor (l 32, 542)/
Touch screen (l 66)
5
Rear tally lamp (l 242)
6
[ ] (AF mode) button (l 97)
7 [AF ON] button (l 98)
8
Focus mode lever (l 96, 97, 123)
9
Joystick (l 66)/
Fn buttons (l 367)
Centre: Fn8, 3: Fn9, 1: Fn10,
4:Fn11, 2: Fn12
10 [Q] (Quick menu) button (l 73)
11
Cursor buttons (l 65)/
Fn buttons (l 367)
3: Fn13, 1: Fn14, 4: Fn15,
2: Fn16
12
Control dial (l 65)
13
[MENU/SET] button (l 65, 77)
14
[ ] (Cancel) button (l 79)
15
[ ] (Delete) button (l 357)
16
[DISP.] button (l 70)
0 The following buttons light when the camera on/off switch is set to [ ].
The lighting timing can be changed in [Illuminated Button] in the [Custom]
([Operation]) menu. (l 429)
–[(] button/[Q] button/[ ] button/[ ] button/[DISP.] button
