10. The Final Transmission Assembly
10-2
111
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 10: THE FINAL TRANSMISSION ASSEMBLY
Topic Page
General Information 10-2
Dismantling the Final 10-3
Transmission Assembly
Replacing Bearing 10-4
(on the side of the
transmission gearbox cover)
Topic Page
Replacing the Bearing 10-5
(on the side of the crankcase)
Assembling the Final Gear Set 10-5
General Information
•Designated oil: SAE 90# Gear Oil
•Filling 0.12L 4 ounces
•Changing 0.10L 3.5 ounces
•Bearing pulling set 12mm
•Bearing pulling set 15mm
•Sleeve shaft for assembling the crankshaft
•Sleeve lever for assembling the crankshaft
•Bearing outer race driver 3740mm
•Bearing outer race driver 3235mm
•Guide lever for the bearing driver 17mm
•Guide lever for the bearing driver 15mm
•Guide lever for the bearing driver 12mm
•Bearing driver
Troubleshooting
The scooter doesn’t run after the engine is
started
•The transmission gear failed
•The driving belt is worn or broken
•The clutch failed
Developing abnormal noise when it runs
•The gear is worn, burnt or has damaged teeth
•The bearing is worn and getting loose
Oil leakage
•Too much oil
•The oil seal is broken
