16. Starter System
16-4
169
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 16:STARTER SYSTEM
6. Check the starter motor
housing conductivity. Be sure
there is no conduction current
between the cable terminal and
the starter motor housing.
7. Check conductivity between
the lead terminal and the brush.
Replace them if necessary.
8. Measure the brush length. Its
service limit is 5mm (.2 in.).
Replace it if necessary. Check
brush holder for conduction
current. Replace if necessary.
9. Inspect bearing in front
bracket for smooth rotation and
for looseness when installed.
Replace it if necessary. Inspect
dust cover for wear or damage.
6
9
OIL SEAL
BEARING
