2. Body Cover and Exhaust System
2-4
31
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 2: BODY COVER AND EXHAUST SYSTEM
Right and Left Side Mold
Removal
1. Remove two rear body screws.
2. Remove three screws in either
side of mold.
3. Remove left and right side
panels.
Body under Cover Removal
5. Remove rear body panel.
6. Remove left and right side
panels.
7. Remove two nuts in either side
of body under cover.
8. Remove body cover.
Floor Panel Removal
1. Remove battery cover,
disconnect battery lead and
dismount battery.
2. Disconnect C.D.I. wire and take
it out of battery box.
3. Remove body cover.
4. Remove the speed-limiting
governor.
5. Remove four check bolts in the
floor panel.
6. Remove floor panel.
1 2
7
FLOOR COVER
5
BODY UNDER COVER
NUTS
To Next Page
