6. Engine Removal and Installation
6-3
69
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 6: ENGINE REMOVAL AND INSTALLATION
10. Disassemble the brake
control cable from the
brake control arm.
11. Remove the rear shock
absorber.
12. Remove the engine
support bolt and move the
chassis up the forwards.
13. Support the chassis in
position temporarily.
14. Remove the side stand
spring and side stand.
15. Remove the front
engine support bolt to
disconnect the engine from
the chassis.
16. Separate the engine
from the chassis.
17. Check the condition of
the engine support
isolation mounts. If they
are worn or damaged,
replace them during the
engine installation
process.
12
ENGINE
SUPPORT BOLT
CHASIS
UNDERSIDE OF SCOOTER
16
