P Series User Guide 252
Show the accumulated operation overload ratio. When the operation overload ratio
reaches the set warning level (0x2010), the operation overload warning (W10) sets
off. When it reaches 100%, operation overload alarm (AL-21) set s off.
0x2604 Instantaneous Maximum Operation Overload ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
INT
-
-
0.1%
RO
Yes
-
No
Show the instantaneous maximum of operation overload ratio from the drive. This
value can be reset by resetting the instantaneous maximum operation overload.
0x2605 DC-Link Voltage ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
-
-
Volt
RO
Yes
-
No
Shows DC-Link voltage based on power input.
0x2606
Accumulated Regeneration Overload
ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
INT
-
-
0.1%
RO
No
-
No
Show the accumulated regeneration overload of the regeneration brake due to
regeneration operation. When the value reaches 100%, regeneration overload
alarm (AL-23) set s off.
0x2607 Single Turn Data ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UDINT
-
-
pulse
RO
Yes
-
No
Show the motor’s single turn data. The values are from 0 ~ (encoder resolution-1)
0x2608 Mechanical Angle ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
-
-
0.1deg
RO
Yes
-
No
The motor’s single turn data is represented within the 0.0~359.9range.
0x2609 Electrical Angle ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
INT
-
-
0.1deg
RO
Yes
-
No
Show the motor’s electrical angle within the range of -180.0~180.0.
