Parker P Series User Manual

Parker Hannifin
P Series User Guide 265
0x3008 Start Index Number(0~63) ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 003F
0 to 63
0 - RW No
At all
times
Yes
Set the number(0~63) to operate when starting indexing position.
In the case of the setting value is 64, index number is determined by ISEL0~ISEL5.
0x3009 Index Buffer Mode ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT 0 to 1 0 - RW No
At all
times
Yes
Set how many times memory count START (operation) signals during operating
indexing position.
Set Value
Setting Details
0
Double buffer set (it can remember second times)
1
Single buffer set (it can remember one time)
0x3100
~
0x313F
Index00 ~ Index63
Index00 ~ Index63
SubIndex 0
Number of Entries(Number of entries)
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
USINT
-
11
-
RO
No
-
No
SubIndex 1
Index Type
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
UINT
0 to 10
1
-
RW
No
At all times
Yes
SubIndex 2
Distance
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
DINT
-2147483648 to
2147483647
100000 UU RW No At all times Yes
SubIndex 3
Speed
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
DINT
1 to 2147483647
100000
UU/s
RW
No
At all times
Yes
SubIndex 4
Acceleration
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
DINT
1 to 2147483647
1000000
UU/s
2
RW
No
At all times
Yes
SubIndex 5
Deceleration
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
DINT
1 to 2147483647
1000000
UU/s
2
RW
No
At all times
Yes
