38
Pressing [F2][INPUT] Pressing [F1][BSP]
Press [ENT] to view the STAKEOUT COORD. SETUP screen.
Open the PN, X, Y, Z, PH and PC input window and input each.
Save the data by pressing [F1][SAVE].
Press [ENT] or [ACCEPT] to view the STAKEOUT screen.
Aim at the Stake out point and press the [F1][MEAS] to begin the Stake Out.
Deviation of each value is displayed.
Form of the screen to display deviation of the Stake Out can be changed by the selections of the
“Compare method selection
” in “PREFERENCE” setting.
To display all information at once, To display information with larger character,
select “ALL IN ONE INFO.” select “LARGE CHARACTOR”.
Press [F5][PAGE] to view another screen.
PN POT4
PH 1. 000 m
D H.angle 65° 32’ 14”
D V.angle 43° 43’ 37”
D H. dist.
