1. BASIC OPERATION
1.1 Names of parts
Focus ring
Collimator
Eyepiece
Plate vial
Display panel
Key board
Plate vial
Leveling screw
Base plate
Detaching knob
Tangent screw
Clam
p
screw
Telescope clamp screw
Telescope tangent screw
Battery pack
Battery latch
Instrument height mark
Laser indicator
Objective lens
Top handle
