98
Definition of this function will be affected to the value of the coordinates.
Please, note that the up on the screen of the graphical view always shows “BASIS DIRECTION”.
In addition, position of points doesn’t change on the “GRAPHICAL VIEW” but, value of coordinates
changes according to the setting of “Coordinate axis definition”.
14.2 Input method selection
Select 23. INPUT METHOD and press [ENT] to view the Character INPUT METHOD selection window.
Press [ENT] to select and press [F5][ACCEPT] to enter.
Explanation of the 10 Key system(123/ABC), Full template, Divided template and Matrix system.
1．10 KEY SYSTEM(123/ABC)
Theseis areis the standard input method using the
Alphanumeric and +/- key.
2. Full template
Select each Character by pressing left, right, up and down arrow keys and select each Character by
pressing [F5][SELECT] each time.
3. Divided template
1. COORD. SYSTEM :XYZ
2. INPUT METHOD : FULL
TEMPLATE
3. ACTION METHOD :FIXED PLANE
4. REMOTE METHOD :FIXED PLANE
1. 10 KEY SYS.(ABC)
2. 10 KEY SYS.(
123
)
3. FULL TEMPLATE
4. DIVIDED TEMPLATE
5. MATRIX SYSTEM
To Next Page
