Pentax R-200 Series User Manual

97
Item Description Selection Default ex.1
German
XYZ
ex.2 ex.3
1.
DISP.1
NAME
Name of the 1st Axis on
the screen.
(Ex. It is shown 3rd line of
the “MEASURE” screen.)
Any name X X N E
2.
DISP.2
NAME
Name of the 2nd Axis on
the screen.
(Ex. It is shown 4th line of
the “MEASURE” screen.)
Any name Y Y E N
3.
DISP.3
NAME
Name of the 3rd Axis on
the screen.
(Ex. It is shown 5th line of
the “MEASURE” screen.)
Any name Z Z Z Z
4.
DISP.1
AXIS
Define the direction of the
1st Axis.
1. BASIS DIRECTION
2. RIGHT ANGLE
3. HEIGHT
1. BASIS
DIRECTION
2. RIGHT
ANGLE
1. BASIS
DIRECTION
1. BASIS
DIRECTION
5.
DISP.2
AXIS
Define the direction of the
2nd Axis.
1. BASIS DIRECTION
2. RIGHT ANGLE
3. HEIGHT
2. RIGHT
ANGLE
1. BASIS
DIRECTION
2. RIGHT
ANGLE
2. RIGHT
ANGLE
6.
DISP.3
AXIS
Define the direction of the
3rd Axis.
1. BASIS DIRECTION
2. RIGHT ANGLE
3. HEIGHT
3. HEIGHT 3. HEIGHT 3. HEIGHT 3. HEIGHT
7.
ROTATION
Define the rotation from
the 1 Axis
to the 2 Axis..
1. CW
2. CCW
1. CW 1. CW 1. CW 1. CCW
Example
of
GRAPHIC
AL VIEW
Any name can be defined for each three axis.
For the “DISP.# NAME, it is possible to define same name. However, please note that the same
coordinates value will be displayed.
Three type of the axis can be selected for each three axis.
For the “DISP.# AXIS”, it is possible to define same type of axis. However, please note that the same
coordinates value will be displayed.
CW
X:B.D.
P1
P2
P3
Y: R.A.
Z: Height
CCW
E:B.D.
P1
P2
P3
N: R.A.
Z: Height
CW
Y:B.D.
P1
P2
P3
X: R.A.
Z: Height
CW
N:B.D.
P1
P2
P3
E: R.A.
Z: Height
