14–10
You can clean the air filter with compressed air.
Apply compressed air only from the clean
side of the air filter.
Replace the air filter, if necessary.
If the vehicle has been driven mainly in
dusty areas, clean the air filter at intervals
of 5,000 km.
Wipe the air filter case and seat with a soft
cloth to remove dirt or dust.
CAUTION
• Do not drive with the air cleaner element
removed. Failure to observe this will
cause excessive engine wear.
• Make sure the air filter is not exposed
to oil. It may reduce the effectiveness
of the element.
Air filter cleaning and
replacement
1KR-VE Engine
1NR-VE Engine
Wire harness
1. Unlock the 2 clips.
2. Lift the upper case.
3. Remove the air filter.
1. Detach the wire harness.
2. Unlock the 4 clips.
3. Lift the upper case.
4. Remove the air filter.
