14–27
w WARNING
If the reserve travel is not within
the specification, have the system
checked immediately by an authorised
Perodua Service Centre.
5 - 7 notches
1. Park the vehicle on a level surface.
2. Shift the manual transmission lever in
neutral, or the automatic transmission
lever in P.
3. Firmly depress the brake pedal.
4. Fully release the parking brake.
5. Pull the parking brake lever up slowly, and
count the notches with a force of 196 N
(44 lb, 20 kgf).
6. Check that the number of notch is within
the specification (5 - 7 notches).
Parking brake reserve travel
check
w WARNING
If the number of notches is not within
the specification, have the system
checked immediately by an authorised
Perodua Service Centre.
Sect 14_EN D42L.indd 27 31/10/2019 5:38 PM
