Circuit diagrams
15 Circuit diagrams
15
.01 Reference list for circuit diagrams 95-212 022-95
A1 Controller PCS 2002
A2 Control panel T1
A3 Floppy
B1 Temperature sensor 1 (cartridge)
B2 Pedal
B3 Air volume sensor
B4 Temperature sensor 2 (nozzle)
M1 DC motor (roller bottom)
M2 DC motor (roller top)
M3 DC Motor (tape feed)
E1 Roller down
E3 Nozzle engaged
E4 Nozzle forwards
E10 Coding
E11 Pressure monitor
E12 Foot switch 2 (cut tape)
E13 Not assigned
E14 Knee switch
E15 Increment differential
E16 Decrement differential
E17 Differential correction zero
E18 Key-switch
E20 Light key (optional)
SU10 Signal converter (optional)
IN1 Programmable input 1
IN2 Programmable input 2
F1 Fuse 16A L1
F2 Fuse 16A L2
G1 Power supply unit-24V, 5A
K1 Semi-conductor relay
Q1 Main switch
Y1 Roller down
Y2 Additional blowing off
Y3 Engage nozzle
Y4 Move nozzle forwards
Y8 Tape knife
Y9 Tape clamp
Y10 Roller clamp
Y11 Air jet tape
Y50 Air volume
Y51 Roller pressure
Out1 Programmable output 1
Out2 Programmable output 2
Z1 Mains fi lter
