Heat sealing
53
10.07 Programmed heat sealing with sequences
In the headline, in addition to the sequence number of the selected sequence, the num-
ber of zones, the current zone and the comment for the current program are displayed. For
the current zone all heat-sealing parameters are displayed. The heat-sealing parameters have
been entered during programming and cannot be altered without changing the program. In
addition, in the case of heat sealing with sequence programs, the individual programs be-
longing to the sequence are displayed, and the current program is shown here as an inverse
symbol.
● Select the desired sequence, see Chapter 9.03 Selecting a production type.
Description of the functions
Program selection
The function opens the menu for entering the program number or for choosing the produc-
tion type, see Chapter 9.03 Selecting a production type.
Notepad
This function opens the notepad with program details about the heat-sealing tools to be
used.
Heat sealing program
Press this function to select the appropriate heat sealing program.
Pressing
This function is used to switch on the pressing function. It is possible to choose between
two pressing functions:
- Cold pressing
- Warm pressing
The pedal function is used to switch between cold and warm pressing, see Chapter 7.03 Pe-
dal. During cold pressing the rollers are closed with the set roller pressure. The rollers roll
over the part without tape, with disengaged hot air nozzle. During cold pressing the speed
can be infi nitely adjusted with the pedal function. The differential is switched off. During
warm pressing, the hot air nozzle is also engaged.
Start
(This function appears, when the top feed roller is lowered.)
This function is used to call up the sealing start, analog to pedal function "+2", also see Chap-
ter 7.03 Pedal.
