Preparation
25
9.02 Adjusting the feed roller clearance
The feed roller clearance depends on the thickness of the material to be sealed.
The clearance is adjusted correctly, when one ply of the workpiece fi ts just bet-
ween the feed rollers when the top feed roller is lowered.
● Switch on the machine.
● Lower the top feed roller.
● Adjust the clearance between the rollers with adjustment wheel 1 depending on the
workpiece and sealing method, see Chapter 7.04 Adjustment wheel for roller clearance.
● Loosen knurled nut 2.
● Set the lift limit to match the sealing material and application using cross handle screw 3.
● Tighten knurled nut 2.
Fig. 9 - 04
1
3
2
