Adjustment
83
13.10.01 Machine confi guration
With the machine confi guration function the machine control unit receives the necessary in-
formation about the attached components. If the machine components are changed, care
must be taken to make the appropriate adjustment in the machine confi guration.
● Switch on the machine.
● Call up the input mode.
● Call up the service menu.
● Call up the menu for entering the machine confi guration.
Explanation of the functions
Input mode
This function is used to change to the initial state of the input mode.
Service menu
This function is used to call up the service menu again.
Heat sealing mode
This function is used to change to the heat sealing mode.
Top/bottom feed roller diameter
These functions are used to enter the diameters of the feed rollers installed.
Top/bottom gear factor
These functions are used to enter the gear factor for the top and bottom roller drive.
Air volume control
This function is used to switch the air volume control on or off.
Number of temperature sensors
This function is used to adjust the number of temperature sensors.
Tape knife clearance
This function is used to enter the tape knife clearance to the roller peak.
Rotating direction of the bottom roller
This function is used to change the rotating direction of the bottom roller.
Confi guration of standard post
Confi guration of small backward post
