Adjustment
93
13.12.02 Digital Inputs
HW Term SW Term Function
EIN (ON) 1 X2/2 E1 Roller lowered
EIN (ON) 2 X2/3 E3 Nozzle engaged
EIN (ON) 3 X3/2 E4 Nozzle forwards
EIN (ON) 4 X3/3 E10 Reserved for 2KW/3KW cartridge recog-
nition
EIN (ON) 5 X4/2 E12 Foot switch 2 = cut tape
EIN (ON) 6 X4/3 E13 not assigned
EIN (ON) 7 X5/2 E11 Pressure monitor
EIN (ON) 8 X5/3 E14 Knee switch
EIN (ON) 9 X6/2 E15 Increment differential
EIN (ON) 10 X6/3 E16 Decrement differential
EIN (ON) 11 X7/2 E17 Differential correction zero
EIN (ON) 12 X7/3 E18 Lock/release key-switch for functions
EIN (ON) 13X 8/2 IN1 Programmable input 1
EIN (ON) 14 X8/3 IN2 Programmable input 2
EIN (ON) 16X9/3 E20 Start light barrier tape cutting
13.12.04 Analog Inputs
HW Term SW Term Function
AE1 X35 TEMP1 Temperature sensor 1 (on heating cartridge)
AE2 X36 TEMP2 Temperature sensor 2 (on nozzle tip)
AE3 X16 Not assigned Not assigned (0..10V)
AE4 X17 Not assigned Not assigned (0..10V)
AE5 X18 AIRIN Air volume sensor (4..20mA)
AE6 X19 RPRESSUREIN Roller pressure regulator actual value
control (0..10V)
Pedal X14/8 Pedal Analog foot pedal
13.12.03 Analog Outputs
HW Term SW Term Function Remark
Roller up X33 DC-Motor 2 Roller motor up (slave) DC-Motor
Roller down X34 DC-Motor 1 Roller motor down
(master)
DC-Motor
Tape feed X32 DC-Motor 3 Tape feed motion DC Motor
SSR_EIN X13 SSR-control Heating capacity control
unit
PWM
AOUT1 X24 AIR OUT Air volume control Prop.valve
AOUT2 X23 RPRESSURE OUT Roller pressure set value Pressure
regulating
valve
