Pfaff 8330 User Manual

Adjustment
96
Error: Y4 (1) Cause E4 (1)
Nozzle moved forwards function is defective
Actual status: Nozzle is moved forwards
The motion was too slow
-> Incorrect setting of exhaust air throttle on counter cylinder side
Switch E4 signals incorrect status
-> Incorrect setting of switch E4
-> Switch E4 defective, wire to E4 defective
Actual status: Nozzle is moved back
-> Valve Y4 defective, wire to valve defective
-> Incorrect setting of exhaust air throttle V4.2 on counter cylinder side
Error: Y4 (0) Cause E4 (0)
Nozzle mov
ed back function is defective
Actual status: Nozzle is moved back
The motion was too slow
-> Incorrect setting of exhaust air throttle on counter cylinder side
Switch E4 signals incorrect status
-> Incorrect setting of switch E4
-> Switch E4 defective, wire to E4 defective
Actual status: Nozzle is moved forwards
-> Valve Y4 defective, wire to valve defective
-> Incorrect setting of exhaust air throttle V4.2 on counter cylinder side
