User’s Manual of GS-5220 LCD Series
341
 VLAN Parameters
Object Description
• VLAN ID Filter
Specify the VLAN ID filter for this ACE.
■ Any: No VLAN ID filter is specified. (VLAN ID filter status is
"don't-care".)
■ Specific: If you want to filter a specific VLAN ID with this ACE,
choose this value. A field for entering a VLAN ID number appears.
• VLAN ID
When "Specific" is selected for the VLAN ID filter, you can enter a specific
VLAN ID number. The allowed range is 1 to 4095. A frame that hits this ACE
matches this VLAN ID value.
• Tag Priority
Specify the tag priority for this ACE. A frame that hits this ACE matches this
tag priority. The allowed number range is 0 to 7. The value Any means that
no tag priority is specified (tag priority is "don't-care".)
 ARP Parameters
The ARP parameters can be configured when Frame Type "ARP" is selected.
Object Description
• ARP/RARP
Specify the available ARP/RARP opcode (OP) flag for this ACE.
■ Any: No ARP/RARP OP flag is specified. (OP is "don't-care".)
■ ARP: Frame must have ARP/RARP opcode set to ARP.
■ RARP: Frame must have ARP/RARP opcode set to RARP.
■ Other: Frame has unknown ARP/RARP Opcode flag.
