User’s Manual of GS-5220 LCD Series
343
• Target IP Address
When "Host" or "Network" is selected for the target IP filter, you can
enter a specific target IP address in dotted decimal notation.
• Target IP Mask
When "Network" is selected for the target IP filter, you can enter a
specific target IP mask in dotted decimal notation.
• ARP Sender MAC
Match
Specify whether frames can hit the action according to their sender
hardware address field (SHA) settings.
■ 0: ARP frames where SHA is not equal to the SMAC address.
■ 1: ARP frames where SHA is equal to the SMAC address.
■ Any: Any value is allowed ("don't-care").
• RARP Target MAC
Match
Specify whether frames can hit the action according to their target
hardware address field (THA) settings.
■ 0: RARP frames where THA is not equal to the SMAC address.
■ 1: RARP frames where THA is equal to the SMAC address.
■ Any: Any value is allowed ("don't-care").
• IP/Ethernet Length
Specify whether frames can hit the action according to their ARP/RARP
hardware address length (HLN) and protocol address length (PLN)
settings.
■ 0: ARP/RARP frames where the HLN is equal to Ethernet (0x06)
and the (PLN) is equal to IPv4 (0x04).
■ 1: ARP/RARP frames where the HLN is equal to Ethernet (0x06)
and the (PLN) is equal to IPv4 (0x04).
■ Any: Any value is allowed ("don't-care").
