User’s Manual of GS-5220 LCD Series
95
Logging on to the Managed Switch
1. Use Internet Explorer 7.0 or above Web browser. Enter the factory-default IP address to access the Web
interface. The factory-default IP address is shown as follows:
http://192.168.0.100
2. When the following login screen appears, please enter the default username "admin" with password
“admin” (or the username/password you have changed via console) to login the main screen of Managed
Switch. The login screen in Figure 4-1-2 appears.
Figure 4-1-2: Login Screen
Default User name: admin
Default Password: admin
After entering the username and password, the main screen appears as shown in Figure 4-1-3.
