User’s Manual of IGS-10020HPT-U
106
4.2.4.5 DHCP Server Binding IP Configuration
This page displays bindings generated for DHCP clients. screen in Figure 4-2-4-5 appears.
Figure 4-2-4-5: DHCP server Binding IP page Screenshot
The page includes the following fields:
Object Description
• IP
Display IP address allocated to DHCP client.
• Type
Display type of binding. Possible types are Automatic, Manual, Expired.
• State
Display state of binding. Possible states are Committed, Allocated, Expired
• Pool Name
Display the pool that generates the binding.
• Server ID
Display server IP address to service the binding.
Buttons
: Check this box to refresh the page automatically
Click to refresh the page immediately.
Click to clear selected bindings. If the selected binding is Automatic or Manual, then it is changed to
be Expired. If the selected binding is Expired, then it is freed.
Click to clear all Automatic bindings and Change them to Expired bindings.
Click to clear all Manual bindings and Change them to Expired bindings.
Click to clear all Expired bindings and free them.
