User’s Manual of IGS-10020HPT-U
199
4.3.9.1 MVR Configuration
. This page provides MVR related configuration. The MVR screen in Figure 4-3-9-1 appears
Figure 4-3-9-1: MVR Configuration Page Screenshot
The page includes the following fields:
Object Description
• MVR Mode
Enable/Disable the Global MVR.
The Unregistered Flooding control depends on the current configuration in IGMP/MLD Snooping.
It is suggested to enable Unregistered Flooding control when the MVR group table is full.
• Delete
Check to delete the entry. The designated entry will be deleted during the next save.
• MVR VID
Specify the Multicast VLAN ID.
Be Caution: MVR source ports are not recommended to be overlapped with management VLAN ports.
• MVR Name
MVR Name is an optional attribute to indicate the name of the specific MVR VLAN. Maximum length of
the MVR VLAN Name string is 16. MVR VLAN Name can only contain alphabets or numbers. When the
optional MVR VLAN name is given, it should contain at least one alphabet. MVR VLAN name can be
edited for the existing MVR VLAN entries or it can be added to the new entries.
• IGMP Address
Define the IPv4 address as source address used in IP header for IGMP control frames. The default
IGMP address is not set (0.0.0.0).
