User’s Manual of IGS-10020HPT-U
369
4.8.1.3 Map Upload / Edit
This page allows the clients for uploading e-Map; the file size cannot be over 151k; the screen in Figure 4-8-1-3 appears.
Figure 4-8-1-3: Map Upload / Edit Page Screenshot
The page includes the following fields:
Object Description
• MAP Select
Allows to select Map1/2/3 for uploading Map.
• Description
Indicates the map’s description.
• File size
Shows Map’s size.
• File
Allows to choose and browse specific map file from laptop device.
• Preview Map
The Preview use of Map.
• Current Map
The Current use of Map.
Buttons
: Click to choose the file.
: Click to upload the file.
