User’s Manual of IGS-10020HPT-U
91
4.2.2.10 SNMPv3 Access
Configure SNMPv3 accesses table on this page. The entry index keys are Group Name, Security Model and Security Level.
The SNMPv3 Access screen in Figure 4-2-2-11 appears.
Figure 4-2-2-11: SNMPv3 Accesses Configuration Page Screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Group Name
A string identifying the group name that this entry should belong to. The allowed string length
is 1 to 32, and the allowed content is the ASCII characters from 33 to 126.
• Security Model
Indicates the security model that this entry should belong to. Possible security models are:
any: Accepted any security model (v1|v2c|usm).
v1: Reserved for SNMPv1.
v2c: Reserved for SNMPv2c.
usm: User-based Security Model (USM)
• Security Level
Indicates the security model that this entry should belong to. Possible security models are:
NoAuth, NoPriv: None authentication and none privacy.
Auth, NoPriv: Authentication and none privacy.
Auth, Priv: Authentication and privacy.
• Read View Name
The name of the MIB view defining the MIB objects for which this request may request the
current values. The allowed string length is 1 to 32, and the allowed content is the ASCII
characters from 33 to 126.
• Write View Name
The name of the MIB view defining the MIB objects for which this request may potentially SET
new values. The allowed string length is 1 to 32, and the allowed content is the ASCII
characters from 33 to 126.
Buttons
: Click to add a new access entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
