User’s Manual of IGS-10020HPT-U
174
4.3.6.7 MSTI Ports Configuration
This page allows the user to inspect the current STP MSTI port configurations, and possibly change them as well. A MSTI port is
a virtual port, which is instantiated separately for each active CIST (physical) port for each MSTI instance configured and
applicable for the port. The MSTI instance must be selected before displaying actual MSTI port configuration options.
This page contains MSTI port settings for physical and aggregated ports. The aggregation settings are global. The MSTI Port
Configuration screen in Figure 4-3-6-9 & Figure 4-3-6-10 appears.
Figure 4-3-6-9 : MSTI Port Configuration Page Screenshot
The page includes the following fields:
MSTI Port Configuration
Object Description
• Select MSTI
Select the bridge instance and set more detail configuration.
