User’s Manual of IGS-10020HPT-U
241
Errors
• Total Error Frame
Seconds Summary
Errors
This four-octet field indicates the sum of errored frame seconds that have been
detected since the OAM sublayer was reset.
• Total Error Frame
Seconds Summary
Events
This four-octet field indicates the number of Errored Frame Seconds Summary Event
TLVs that have been generated since the OAM sublayer was reset, encoded as a
32bit unsigned integer.
Buttons
: Click to refresh the page.
: Click to clear the data.
4.3.16.4 Port Settings
This page allows the user to inspect the current Link OAM port configurations, and change them as well, as screen in Figure
4-3-16-4 appears.
Figure 4-3-16-4: Port Status Page Screenshot
