User’s Manual of IGS-10020HPT-U
240
• Total frame errors
This eight-octet field indicates the sum of errored frames that have been detected
since the OAM sublayer was reset.
• Total frame error
events
This four-octet field indicates the number of Errored Frame Event TLVs that have
been generated since the OAM sublayer was reset.
• Frame Period Error
Event Timestamp
This two-octet field indicates the time reference when the event was generated, in
terms of 100 ms intervals.
• Frame Period Error
Event Window
This four-octet field indicates the duration of period in terms of frames.
• Frame Period Error
Event Threshold
This four-
octet field indicates the number of errored frames in the period is required to
be equal to or greater than in order for the event to be generated.
• Frame Period Errors
This four-octet field indicates the number of frame errors in the period.
• Total frame period
errors
This eight-octet field indicates the sum of frame errors that have been detected since
the OAM sublayer was reset.
• Total frame period
error events
This four-octet field indicates the number of Errored Frame Period Event TLVs that
have been generated since the OAM sublayer was reset
• Symbol Period Error
Event Timestamp
This two-octet field indicates the time reference when the event was generated, in
terms of 100 ms intervals.
• Symbol Period Error
Event Window
This eight-octet field indicates the number of symbols in the period.
• Symbol Period Error
Event Threshold
This eight-octet field indicates the number of errored symbols in the period is required
to be equal to or greater than in order for the event to be generated.
• Symbol Period
Errors
This eight-octet field indicates the number of symbol errors in the period.
• Total symbol period
errors
This eight-octet field indicates the sum of symbol errors since the OAM sublayer was
reset.
• Total Symbol period
error events
This four-octet field indicates the number of Errored Symbol Period Event TLVs that
have been generated since the OAM sublayer was reset.
• Error Frame
Seconds Summary
Event Timestamp
This two-octet field indicates the time reference when the event was generated, in
terms of 100 ms intervals, encoded as a 16-bit unsigned integer.
• Error Frame
Seconds Summary
Event window
This two-octet field indicates the duration of the period in terms of 100 ms intervals,
encoded as a 16-bit unsigned integer.
• Error Frame
Seconds Summary
Event Threshold
This two-octet field indicates the number of errored frame seconds in the period is
required to be equal to or greater than in order for the event to be generated, encoded
as a 16-bit unsigned integer.
• Error Frame
Seconds Summary
This two-octet field indicates the number of errored frame seconds in the period,
encoded as a 16-bit unsigned integer.
