User’s Manual of IGS-10020HPT-U
230
4.3.14.2 GVRP Port Configuration
This configuration can be performed either before or after GVRP is configured globally - the protocol operation will be the same.
as well. as screen in Figure 4-3-14-2 appears.
Figure 4-3-14-2: GVRP Port Configuration Page Screenshot
The page includes the following fields:
General Settings
Object Description
• Port
The logical port that is to be configured.
• Mode
Mode can be either 'Disabled' or 'GVRP enabled'. These values turn the GVRP
feature off or on respectively for the port in question.
Buttons
: Click to refresh the page. Note that unsaved changes will be lost.
: Click to undo any changes made locally and revert to previously saved values.
