User’s Manual of IGS-10020HPT-U
83
4.2.2.4 SNMP Trap Configuration
Configure SNMP trap on this page. The SNMP Trap Configuration screen in Figure 4-2-2-4 appears.
Figure 4-2-2-4: SNMP Trap Configuration Page Screenshot
The page includes the following fields:
Object Description
• Trap Config
Indicates which trap Configuration's name for configuring. The allowed string
length is 0 to 255, and the allowed content is ASCII characters from 33 to 126.
• Trap Mode
Indicates the SNMP trap mode operation. Possible modes are:
 Enabled: Enable SNMP trap mode operation.
 Disabled: Disable SNMP trap mode operation.
• Trap Version
Indicates the SNMP trap supported version. Possible versions are:
 SNMP v1: Set SNMP trap supported version 1.
 SNMP v2c: Set SNMP trap supported version 2c.
 SNMP v3: Set SNMP trap supported version 3.
• Trap Community
Indicates the community access string when send SNMP trap packet. The
allowed string length is 0 to 255, and the allowed content is the ASCII characters
from 33 to 126.
• Trap Destination
Address
Indicates the SNMP trap destination address.
• Trap Destination Port
Indicates the SNMP trap destination port. SNMP Agent will send SNMP message
via this port, the port range is 1~65535.
