User’s Manual of IGS-10020HPT-U
273
4.5.1.2 Access Management Statistics
This page provides statistics for access management. The Access Management Statistics screen in Figure 4-5-1-2 appears.
Figure 4-5-1-2: Access Management Statistics Overview Page Screenshot
The page includes the following fields:
Object Description
• Interface
The interface that allowed remote host can access the switch.
• Receive Packets
The received packets number from the interface under access management
mode is enabled.
• Allow Packets
The allowed packets number from the interface under access management
mode is enabled.
• Discard Packets
The discarded packets number from the interface under access management
mode is enabled.
Buttons
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
: Clears all statistics.
