User’s Manual of IXT-900 PoE series
140
4.4.2.4 CoS Mapping
The CoS to Queue and Queue to CoS Mapping screens in Figure 4-4-7 & Figure 4-4-8 appear.
Figure 4-4-7 CoS to Queue and Queue to CoS Mapping Page Screenshot
The page includes the following fields:
Object
Description
 Queue
Select Queue value for this drop down list.
 Class of Service
Select CoS value for this drop down list.
Buttons
: Click to apply changes.
