4.4.5 Storm Control
Storm control for the switch is configured on this Page.
There is an unknown unicast storm rate control, unknown multicast storm rate control, and a broadcast storm rate control.
These only affect flooded frames, i.e. frames with a (VLAN ID, DMAC) pair not present on the MAC Address table.
4.4.5.1 Global Setting
The Storm Control Global Setting and Information screens in Figure 4-4-23 & Figure 4-4-24 appear.
Figure 4-4-23 Storm Control Global Setting Page Screenshot
The page includes the following fields:
Object
Description
 Unit
Controls the unit of measure for the storm control rate as "pps" or "bps". The
default value is "bps".
 Preamble & IFG
Set the excluded or included interframe gap
Buttons
: Click to apply changes.
Figure 4-4-24 Storm Control Global Information Page Screenshot
The page includes the following fields:
Object
Description
 Unit
Display the current unit.
 Preamble & IFG
Display the current preamble & IFG.
