User’s Manual of IXT-900 PoE series
74
4.2.4.8 SNMPv3 Notification Recipients
Configure SNMPv3 notification recipients on this page. The SNMPv1, 2 Notification Recipients screens in Figure 4-2-33 and
Figure 4-2-34 appear.
Figure 4-2-33 SNMPv3 Notification Recipients Screenshot
The page includes the following fields:
Object
Description
 Server Address
Indicates the SNMP trap destination address. It allows a valid IP address in
dotted decimal notation ('x.y.z.w'). It can also represent a legally valid IPv4
address. For example, '::192.1.2.34'.
 Notify Type
Set the notify type in traps or informs.
 User Name
Indicates the user string when send SNMP trap packet.
 UDP Port
Indicates the SNMP trap destination port. SNMP Agent will send SNMP message
via this port, the port range is 1~65535.
 Time Out
Indicates the SNMP trap inform timeout. The allowed range is from 1 to 300.
 Retries
Indicates the SNMP trap inform retry times. The allowed range is from 1 to 255.
Buttons
: Click to add a new SNMPv3 host entry.
Figure 4-2-34 SNMPv3 Host Status Screenshot
The page includes the following fields:
Object
Description
 Server Address
Display the current server address
 Notify Type
Display the current notify type
 User Name
Display the current user name
 UDP Port
Display the current UDP port
 Time Out
Display the current time out
 Retries
Display the current retry times
 Action
: Delete the SNMPv3 host entry
